| Message: | When using current transformers, the accuracy of measurement determined by the primary current amplitude error (contrast) and phase error (difference). In medium accuracy without the requirement of DC component of electric meter, the absolute value of these two is very low, but it can be compensated through the relevant correction circuit. DC component of current transformer is different, because the difference of its phase difference is large and stable. The special characteristic of amplitude error is relatively small. There is an energy measurement error. The error changes with the primary current. If the phase difference don't compensate, it cannot be applied in high perceptual load.
Part Number DC current core dismension(mm) precision
A OD ID HT grade
EF02R01908 40 19 14 8 0.1
EF02R02010 40 20 14 10 0.1
EF02R02108 60 21 14 8 0.1
EF02R02110D 60 21 16 10D 0.1
EF02R02110 60 21 16 10 0.1
EF02R02210 60 22 16.5 10 0.1
EF02R02310 60 23 16 10 0.1
EF02R02408 60 24 17 8 0.1
EF02R02410 80 24 18 10 0.1
EF02R02808 80 28 17 8 0.1
EF02R02315 100 23.5 16.5 15 0.1
EF02R02508 100 25 16 8 0.1
EF02R02610 100 26 19 10 0.1
EF02R02708 100 27 19 8 0.1
EF02R02810 100 28 19 10 0.1
EF02R03008 100 30 20 8 0.1
EF02R02510 120 25 16 10 0.1
EF02R02712 120 27 19 12 0.1
EF02R02812 120 28 19 12 0.1
EF02R03006 120 30 21 6.5 0.1
EF02R02715 150 27 18 15 0.1
EF02R03310 160 33 23 10 0.1
EF02R03315 200 33 23 15 0.1
We can make customized dimension and specification.
|
