| Message: | This line is professional equipment is used for processing the hot rolled steel coil into the desired length steel plate ( thickness: from 4mm to 25mm) and stacking them in order through decoiling, leveling, measuring and shearing.FeaturesIt is mainly composed of the decoiler, pinch roll and leveler, length controller, shearer and stacker etc., accompany of the feeder, side guider, conveyor etc. For "SS" or "P+O" material, auto stacker will work for them. Edge trimming and scrap recoiler is optional for material request.Process FlowStorage Platform → Coil Lifter → Decoiler → Snubber Roller + Pinch Roll + Pre-Leveler → Conveyor → Pinch Roll → Side Guide Device → Leveling Machine → Measuring Roller → Shearing Machine → Conveyor and Pneumatic Pinch Roll →Unload CartMachine ConfigurationNo.ItemQty1Coil Platform2 pcs2Hydraulic Coil Lifter1 set3Hydraulic Decoiler1 set4Snubber Roller; Pinch Roll + Pre-Leveler1 set5Conveyor1 set6Pinch Roll1 set7Side Guide1 set8Levelling Machine1 set9Measuring (Encoder)1 set10Shear & Scrap Cart1 set11Conveyor with Pinch1 set12Unload Cart1 set13Hydraulic System1 set14Pneumatic System1 set15Electric System1 setTechnical ParameterMaterialHot rolled steel coilThickness1-4mm; 2-6mm; 2-8mm; 2-10mm; 3-12mm; 4-16mm; 6-20mm; 8-25mmWidth1600 / 1850/ 2000/ 2200 / 2500mmWeight20 / 25 / 30 / 35 TSpeed0~18m/minPhotos for ReferenceDouble-cone DecoilerLevelerSnubber RollerPinch Roll + Pre-LevelerMeasuringShearingStacker url:http://www.tubemills-reliantt.com |
