| Message: | RTQC series high speed (0-80m/min leveling speed) metal/steel coil cut to length machine is also named cut to length line/ decoiling line/ shearing line/ leveling line/ blanking line.FeaturesIt is used for processing the CR/ pre-painted or galvanized steel and stainless steel coils less than 3mm thickness through decoiling, leveling & cutting then turned into flattened plate with desired length.We also can supply the low speed (0-24m/min) cut to length line, stainless steel cut to length machine, heavy gauge leveling line, and high speed/ low speed slitting line, heavy duty slitter machine, slitting and cut to length line.Process FlowMachine ConfigurationNo.ItemQty1Coil Saddle2 pcs2Coil Lifter1 set3Hydraulic decoiler1 set4Snubber Roller1 set5Pinch Roll & Leveler1 set6Loop bridge NO.11 set7Side Guide Roller1 set8Pinch Roll+ Precision Leveler1 set9Shear1 set10Conveyor1 set11Pneumatic Stacker1 set12X-Lifting Platform1 set13Unload Cart2 sets14Hydraulic + Pneumatic System1 set15Electric System1 setTechnical ParameterMaterialCR, galvanized, color coated steelThickness Range0.5-3mmWidth Range600-1500mmCoil Weight15TCoil I.D.508mmCutting Length500-4000mmWorking Speed0~80m/minMachine Total Power140KWMachine Space28×8.5mPhotos for ReferenceHydraulic DecoilerLevelerLoop BridgePrecision LevelerShearStacker url:http://www.tubemills-reliantt.com |
