| Message: | This Sheet Metal Processing Coil Slitting Line is used for processing the hot rolled steel coils less than 20mm thickness through decoiling and slitting and then turned into steel strip coils with desired width with semi-automatization.FeaturesThis Slitting Sheet Production Line is professional equipment which used for slitting the wide raw coil into narrow strips of HR ( thickness: from 4mm to 20mm) in order to prepare material for subsequent processing as milling, pipe welding, cold forming, punch forming, etc. It is mainly composed of the decoiler, pinch roll and leveler, slitter, recoiler etc., accompany of the feeder, side guider, conveyor, shear, scrap recoiler etc.Process FlowTechnical ParameterMaterialHot rolled steel coilThickness1-4mm; 1.5-5mm; 2-6mm; 2-8mm; 2-10mm; 3-12mm; 4-16mm; 6-20mmWidth1600 / 1850/ 2000/ 2200 / 2500mmWeight20 / 25 / 30 / 35 TSpeed0~25m/minPhotos for ReferenceDecoiler +Coil LifterSlittingSnubber roller + Pinch RollPre-Leveler + ShearScrap RecoilerLoop BridgeDampingRecoilerUnload CartFinished Strip Coils url:http://www.tubemills-reliantt.com |
