| Message: | YT/AEEF Three-phase Electric Induction MotorSpecifications
1.Used in machine tools/pumps/fans/transport machinery/mixer
2.CE certification
3.100% copper wire.
4.cold or hot laminatioYT/AEEF three-phase electric induction motor 15kw
Technical parameter
1,Frame size:H56-355;
2,Power:0.12-355Kw;
3,Voltage:220-660V;
4,Rated Frequency: 50 Hz / 60 Hz;
5,Poles: 2 / 4 / 6 / 8 / 10
6,Speed: 590 -2980 r/min
7,Ambient Temperature: -15°C-40°C
8,Model of CONEECTION: Y-Connection for 3 KW motor or less while Delta-Connection for 4 KW motor or more;
9,Mounting: B3; B5; B35; B14; B34; V1;
10,Current: 1.5-465 A (AC);
11,Duty: continuous (S1);
12,Insulation Class: F;
13,Protection Class: IP54;
14,Frame material: aluminium body(56-132 frame), cast iron(71-355 frame)
15,Cooling Method: IC411 Standards;
16,Altitude: No more than 1,000 meters above sea level;
17,Packing: 63-132 frame be packaged by carton&pallets
160-355 frame be packaged by plywood case url:http://www.xitanghongda.com |
