Anti explosion 4-20mA Output 2088 pressure transmitter is the most popular transmitter and Industrial explosion-proof shell, been widely used in Harsh environment of petroleum and chemical industry etc.
Main Features
1) Diffusion silicon sensor .
2) Wide range.
3)High protection grade, high precision and good stability.
4) Digital pressure display LCD for double Output signal 4~20mA/RS485
5) Having the functions of conversion Various metering units counting
6)self-contained power, after the instrument power-off, can Sustainable work 48 hours
7) Shock resistance, vibration resistance, applicable in industrial field and explosion-proof.
Specification
PRESSURE RANGE -0.1~0...100MPa
ACCURACY 0.25%F.S
STABILITY ≤0.1%/year
POWER SUPPLY 12~30VDC
WORK TEMPERATURE -30°C~80°C
MEDIA TEMPERATURE -40°C~150°C(Temperature over 80C shall equipped with heat radiator)
OVERLOAD CAPACITY 150%F.S
BURST CAPACITY 300%F.S
PRESSURE TYPE Gauge pressure/Absolute pressure(vacuum)/seal pressure
RELATIVE HUMIDITY 0~90%
PROTECTION LEVEL/IP RATING IP65
MEDIA Gas/Liquid/Oil etc
Sensor Diffused silicon
Display Led/Lcd url:https://www.mrcsensor.com |
