Solid Copper Core PVC Insulated (BV) Electrical Wire

Create: 09/19/2018

Expired Date:	09/28/2019
Category:	Electrical cable [Equipment&Machinery]
Message:	Solid Copper Core PVC Insulated (BV) Electrical Wire Conductor: Solid copper wire according to IEC60228 Class 1 Stanard: IEC 60227; GB/T5023; JB 8734 or as requirement Application: Applicable to fix installation of power devices for A.C. rated voltage up to 450/750V Maximum temperature of conductor: 70 degree Celsius Minimum installation environment temperature: 0 degree Celsius Bending radius: Min. 4 times of O.D. Complete wire to be setted in the water at 20 degree Celsius for 1 hour, at the testing voltage for 5 minutes, no breakdown should be found on the whole wire. Rated voltage / Testing voltage: 300V / 2000V Rated voltage / Testing voltage: 450V / 2500V






City:	Jiaxing[CN]
